Depress brake pedal and hold depress control switch and hold release brake pedal. Wire per diagram on next page.
Dc4 Hurst Roll Control Wiring Diagram Wiring Library
Hurst roll control wiring diagram. Pistol grip roll control switch the pistol grip quarter stick shifters come equipped with a precision snap action 12 volt switch that is ideal for operating the hurst rollcontrol nitrous oxide systems trans. To release brakes release. Following the wiring recommendation properly will prevent accidental engagement of the hurst roll control system. Complete the next steps within 60 seconds. For added safety two switches arming and activation are provided in this kit. The diagram shows a to the right of the solenoid and the solenoid has a red wire but it doesnt get wired to positive hot battery until after it goes through the momentary switch then master toggle then fuse.
To actuate the hurst rollcontrol system launch control automatic vehicles only. Suggested ground and 12v source. Using a length of 18 gauge wire splice one end to the 3 wire of the rollcontrol switch and con nect the other end to a switched positive terminal so that the rollcontrol is only operable with the ig nition turned on. All wiring connections should be soldered and covered with shrink sleeving. The fuse can protect the electrical system in the event of a short circuit. See wiring diagram for wiring details and should be incorporated into the wiring circuit.
It is a normally open momentary contact quick release switch with a maximum 10 amp. Holding the solenoid valve closed for more than 60 seconds can cause the fuse to burn out perma nently damaging the solenoid valve andor result in other damage. The hurst roll control solenoid valve is designed for 12v dc operation only. For added safety two switches arming and activatiois kit. Following the n are provided in th wiring recommendation properly will prevent accidental engagement of the hurst roll control system. Arm the hurst roll control system by depressing the rocker arm switch to the on position the engage button switch should illuminate.
Installed hurst roll control wiring installation note. Reconnect battery and test for correct operation. The wire from the lamp 2 wire from the roll control switch and 4 wire from solenoid valve. See hurst roll control operation for competiton use caution. The hurst rollcontrol is used primarily in drag racing to provide positive locking action to the front wheels of race cars reducing the chance of rolling the lights and producing more effective burn outs for heating up the tires. De activate switch off arming switch when the hurst roll control is not in use to prevent accidental engagement.
The other diagramnot above in the manual is clear for color codes and order. Disconnect negative battery terminal. Hurst roll control installation instructions 5671517 2008 2010 challenger srt8 w 4 port system. The hurst roll control solenoid valve is designed for 12v dc operation only. Rigorous testing has proved a 1100000 of a second release time and vibration tests have seen up to 30 gs applied without mechanical failure. Brakes are now locked.
With the vehicle staged fully depress and hold the brake pedal.
