Megatune injector settings dialog required fuel setup 106. Injectors injectors flyback rail coolant and inlet air temp sensors.
Download Cat 3 Wiring Diagram Rj11
Vems wiring diagram. Four cylinder coil on plug wiring diagram 122. Megatune fan water and fuelpump settings dialog fuel pump relay setup 121. Some bosch type sensors are 3 wire type pin3 is the cables shield. Here is a diagram illustrating the driver chip locations on the circuit board relative to channel number. There are at least four versions of the vga connector which are the three row 15 pin de 15 also called mini sub d15 in original and ddc2 pinouts a less featureful and far less common 9 pin vga and a mini vga used for laptops. Ec36 bare connector ec36conn 2500.
Econoseal connector kit ec18conn ec36conn 4000. The image and below table are the newer 15 pin vga vesa ddc2 connector pinout. Vems v32 ecu 188 wiring diagram bmw e30 m20b25 engine. Ec18 bare connector ec18conn 1500. It has been developed by motorsports enthusiasts to provide other enthusiasts with a complete system with features only found in the more expensive high end engine management systems. This diagram can be used to a lot of german cars wiring diagram.
Fuel pump wiring diagram 105. Ev1 injector connector ev1injconnector 350. Otherwise the wiring schematic for batch injection is trivial. Professional assembly testing and an amazing forward thinking tuning software that makes tuning quick and easy. Note that injection wiring is independent from ignition so if you list 4 ignition types and 2 injection it does not make sense to convolute them make 24 drawing. The standard ec18 wiring since 2009 09 29.
Vems features an advanced injector control system which can control high impedence injectors with incredible precision. Vems us info at vemsus. Single coil wiring diagram 123. On either type of sensor the shield should be grounded near or on the engine block. Econoseal jpt crimptool jptcrimptool 5500. Vems acts as a switch between the component injector relay ignition coil and ground.
Main relay fuel pump relay fusebox sensors clt iat tps etc groundings gnd ohjaustransistorien maadoitukset gnd5 rs 232 ecu programming cable wideband oxygen sensor. Vga ddc2 connector pinout. Ethanol sensor connector ethanolsensconn 1100. We do not want to promote batch injection it only has disadvantages many small ones that one can live with but why. Typical eight injector wiring diagram 103. Vw corrado wiring diagram.
More printouts for v3x v3x pin information in pdf format. Vems does not provide the power to these components. Vems gives you the full engine control that you need to bring out the best performance from your turbosupercharged or normally aspirated engine. Parallel injector wiring diagram 104. Vems is for someone who wants the best control of their engine with a budget in mind. Versatile engine management systems vems wiki.
The integrated wideband controller makes the tuning and afer the fact closed loop control simple and very effective.
