Nlight is your network lighting controls system with wired or wireless options that is easy to specify install and use that grows with your business today and tomorrow. Page 5 eclypse enclosure nlight eclypse wiring diagram knockout knockout high voltage usb 1 usb 2 nlight port 1 nlight port 2 din rail din clip nlight port 3 supports ethernet secondary modbus gfx module rs 485 ethernet primary knockout knockout acuity brands one lithonia way conyers ga 30012 phone.
Automatedbuildings Com Interview Trevor Palmer
Nlight eclypse wiring diagram. The nlight eclypse provides time based control of an nlight andor xpoint wireless network as well as acting as the ip interface for sensorview software. Providing system power and switching lighting loads. So for the first time you can unlock the power of time based controls and demand response tap into the capabilities of envysion and sensorview software and enable a hybrid nlight wired and wireless control system with a single pane of glass. Rj 45 male terminations t568b 1500 ft max cable length per zone. With nlight you can control indoor and outdoor spaces seamlessly while reducing energy costs aiding in building code compliance improving occupant comfort and much more. This btl listed b bc controller leverages native bacnetip and wifi to let you seamlessly integrate your lighting control system with your building management system.
A unique conceptual diagram. The device in an nlight network that connects the network of sensors power packs wallpods and bridges to the buildings ethernet. This section includes a set of fixture connection diagrams each with a similar format. The nlight device is typically also a power pack and can provide power to a local sensor. Find code industry and system specific typicals provided by acuity brands. Nlight eclypse system controller by nlight.
Contents 1 nlight control system overview 04 11 introduction 04 12 system architecture 05 121 nlight enabled device 05 122 nlight control zone 06 123 nlight channel 07 124 nlight operational mode 10 125 nlight backbone network 14 13 system power 16 14 system control 17 2 hardware installation 18 21 install backbone 19 22 install zones w power packs 20. Consisting of a server module power supply module nlight network interface module the nlight eclypse expands the capacity and functionality of the series 2 nlight gateway with a native. The nlight npp16 series power pack is the workhorse of an nlight system. Also get cad risers and wiring diagram documents and resources. Nlight eclypse extends the power of nlight to deliver the next level of lighting control. See maximum distances per wire gauge in fixture installation instructions.
To provide system power the power pack transforms class 1 line voltage 120277 vac or 347 vac to class 2 15 vdc. Requires a network drop similar to a network printer. Each unit has two important responsibilities. The nlight air wireless controls adapter is a device that connects your nlight air control system to the nlight eclypse.
