Applies to most but not all older mercedes 1973 to 1993. The wiring diagram shows two wires from the dash switch to the antenna the switch just swaps over 12v and ground to the motor for up or down.
1985 Mercedes Benz 380sl Wiring Diagram To Hook Up Hirschmann
Hirschmann antenna wiring diagram. I have a factory hirschmann antenna that needs the wiring harness. With 12v constant it will finish retracting when you turn the car off. This could be sourced from the. I dont have a diagram but i can tell you that you need 12vdc going to the antenna for power. New replacement hirschmann power antennas have black white and red wires i opened a box to check and wiring diagram suggests constant 12 v. Can anyone tell me or show a picture of the original harness with colors lengths and where the connections go in car.
Reason if you turn the car off and the power wire is ignition switched it will stop retracting as soon as key is off. Hirschmann wlan products wireless lan user manual wlan outdoor guide rel. Hirschmann antenna wiring diagram wiring diagram is a simplified pleasing pictorial representation of an electrical circuit. It shows the components of the circuit as simplified shapes and the capacity and signal associates with the devices. Link to detailed repair video and replacement parts. Your replacement antenna is like what i have it gets permanent always on 12v on red ground on black and blue gets a signal from a connector on the radio power amp 12v is up nothingground is down.
