Check the delay of the leakage alarm. Unit operates on 24 vac 24 vdc or 120 vac supply.
Fv 1627 Flygt 3068 Wiring Diagram Download Diagram
Flygt minicas wiring diagram. Overtemperature relay contacts. Wiring diagram minicas llfus 120 mode of operation. It is designed for the 3000 series pumps up to model 3301 and for the mixer program. Leakage relay contacts. High temperature and leakage. If pump shutdown is desired for a leakage situation connect minicas contacts 1 3 11 8 in series.
Flygt minicas wiring diagram wiring diagram is a simplified suitable pictorial representation of an electrical circuit. 11 8 closed 11 9 open. 2 reset leakage 10 s 8 11 9 high temp 4 13 6 2 power supply 24 v acdc 120 v ac and 230 v ac 12 vdc 7 5 minicasii sensor. Overtemperåture indication note leakage indica tion. This version also has an. In case of alarm the pump is stopped or an alert is given by means of lamps and relays.
Please see technical data. The updated version has a 10 s delay. 1 3 closed 1 4 open. They lower your energy bill and reduce unplanned maintenance costs. Flygt n pumps take on the toughest applications and get the job done. Installation wiring relay outputs wiring relay outputs illustration this is an illustration of section 6 of the base unit terminal block.
Wiring diagram minicas fus us version wiring diagram minicasfus see note 2 notes. Thanks to patented n technology with its innovative self cleaning impeller flygt n pumps deliver the highest total efficiency. Thermal switches for stator overtemperature. In normal conditions when the minicas 120 is powered the green led is on and the relay contact status is as follows. Every component is designed and manufactured to deliver sustained high efficiency. A number of condition monitoring sensors are available for the itt flygt pump range.
It shows the components of the circuit as simplified shapes and the capability and signal friends amid the devices. Go relay pump interlock 5a250v ac. 24 vac24 voc 120 vac 2. The circuit diagram on the side of the unit. Wiring diagram minicas llfus 120. Wiring diagram minicas fus us version pump housing thswitch lk.
Minicas ii is a monitoring relay used primarily with small and medium pumps and mixers. Amber led indicates supply on. Cls for water in oil detection. It provides protection for the most common threats against a submersible pump. The original version has a 5 s delay. Itt flygt minicas ii is a supervision relay for tempera ture and leakage sensors.
Minicas ii resets automatically after leakage fault. Control transformer required only for 24 vac applications. Terminal this table describes the terminals for the relay outputs. There is not a separate indication when two leakage sensors are used. Dc power supply required for 24 vdc. The sensors are monitored by the itt flygt minicas ii supervision relay which is situated in the panel.
Wiring diagram minicasfus control transformer fl minicas 12 10 ac neutral see cc yel blu vdc orn starter in terlocking circuit 120 vac rgnd notes. Minicas ii requires resetting after overtemperature fault. Description terminal description number go relay pump interlock 5a250v ac.
