Appendix b shows the dimensions of the devicenet devices. Figure 22 wiring diagram 24v dc inputrelay output cat.
Physical Layer Ppt Video Online Download
Devicenet wiring diagram. The wiring diagram for each specific type is located on the right side of the device housing. 100 dny42r shown dnet 24v red can h white can l blue dnet 24v black 4 3 2 1. Whats in this chapter this chapter introduces the devicenet cable system and provides a brief overview of how to set up a devicenet network efficiently. Optional module devicenet interface connector h hw mode devicenet line shield canh canv white red modstat module status led as defined in spec. Tr terminating resistor component description trunk line the network cable between terminators. Dsa wiring diagrams figure 22 through figure 24 shows typical wiring diagrams for three versions of the dsa module.
Devicenet uses a trunk line and drop line topology to connect nodes for communication. Drop line the network cable between the trunk and nodes. Here is an example. 11212011 123737 pm. Each drop line may be no longer than 6 meters. For information on this topic see page before you begin 1 2 set up a devicenet network 1 4 understand the.
62 wiring diagram the devicenet interface is connected to the actuator terminal board by internal wiring as shown below. The steps in this chapter describe the basic tasks involved in setting up a network. 3 devicenet adaptation for cip chapter 7. Section 3 describes the devicenet communications power supply methods and provides a step by step procedure to determine the ideal location for the power supply or power supplies appendix a provides lists of omrons devicenet devices. It is usually a thick cable. Devicenet planning and installation manual author.
